Laboratory Tender, Lab Catalog Description and Lab Specifications
|
Capacity
|
2000kN
|
3000 kN
|
|
Standard
|
EN
|
EN
|
|
The roughness value for
texture of loading and auxiliary platens
|
≤ 3.2 µm
|
≤ 3.2 µm
|
|
Lower platens dimensions
(dia.)
|
300 mm
|
300 mm
|
|
Upper platens dimensions
(dia.)
|
300 mm
|
300 mm
|
|
Maximum vertical
clearance between platens
|
340 mm
|
340 mm
|
|
Piston diameter
|
250 mm
|
300 mm
|
|
Maximum piston movement
|
50 mm
|
50 mm
|
|
Horizontal clearance
|
360 mm
|
425 mm
|
|
Power
|
750 W
|
750 W
|
|
Oil capacity
|
20 L
|
20 L
|
|
Maximum working pressure
|
410 Bar
|
410 Bar
|
|
Dimensions (W x L x H)
(mm)
|
810x500x970
|
810x500x970
|
|
Weight
|
795 kg
|
1095 kg
|
-->
Dufon Dufon Automatic Digital Compression Testing Machine are leading Manufacturers India for Lab, Dufon Automatic Digital Compression Testing Machine Manufacturer India, Dufon Automatic Digital Compression Testing Machine Lab Suppliers, Dufon Automatic Digital Compression Testing Machine, Dufon Automatic Digital Compression Testing Machine in India, Dufon Automatic Digital Compression Testing Machine Exporter, Dufon Automatic Digital Compression Testing Machine School Lab Tender Specifications
